Feature & Use:

• Automatic turret shifting between penetrator and objective lens, RS232 data interface, built-in printer

• Hardness conversion between different hardness scales

• Precision conforms to GB/T 4340.2, ISO 6507-2 and ASTM E384

     It can be used to determine the Vickers hardness of steel, non-ferrous metals, ceramics, treated layers of metal surface, and the hardness grads of carburized, nitrided and hardened layers of metals. It is also suitable to determine the Vickers hardness of micro and super thin parts.

Specifications

   Measuring range: 5-3000HV

   Test force: 0.09807, 0.2452, 0.4904, 0.9807, 1.961, 2.942, 4.904, 9.807N

                   (10, 25, 50, 100, 200, 300, 500, 1000gf)

   Hardness scale: HV0.01, HV0.025, HV0.05, HV0.1, HV0.2, HV0.3, HV0.5, HV1

   Magnifications of the measuring system: 400X (measuring),

                                                              100X (observing)

   Min. scale value of the optical micrometer: 0.01μm

   Measuring range: 200μm

   Max. height of test piece: 75mm

   Depth of throat: 110mm

   Power supply: 220V AC or 110V AC, 50 or 60Hz

   Dimensions: 470 x 320 x 500mm

   Weight: approx. 40kg

Standard accessories

   Coordinate anvil: 1 pc. (Table size: 100 x 100mm, travel: 25 x 25mm,

                                     grade division of micrometer head: 0.01mm)

   Thin shaft anvil (Ø 0.3- Ø 5mm): 1 pc.

   Thin plate anvil: 1 pc.

   Flat nose pliers: 1 pc.

   Large V-notch anvil: 1 pc.

   Small V-notch anvil: 1 pc.

   Diamond pyramid penetrator: 1 pc.

   Micro-Vickers standardized block: 2 pcs.

Optional accessories

   Knoop penetrator

   CCD camera and image processing system

1.Are your company a trading one or a factory ?

Factory + trade (integration),15 years focusing on test instruments field,7 years exporting experience.

OEM is also acceptable for us.

2.How to choose the most suitable products?

Our professional team will give you the best suggestion as long as you tell us what kind of test you

need to do and the required specification.

3.What’s the delivery term?

At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20

working days after deposit receipt. If you are in urgent need, we can consider making special

arrangement for you.

4.Do you accept customization service?

Yes, of course, we can not only offer standard machines, but also customized machines according to

your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.

5.Can we visit your factory before order?

Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to

arrange hotel and pick up you from airport.

6.Do you have customers of our country before?

Now our testing machines have been sold to more than 120 countries, like USA, Canada, Russia,UK,

Italy, Germany, European Union, India, Pakistan, Philippines, Singapore, Thailand and Vietnam,Iran,

Brazil and so on.

7.How about your warranty?

Generally, our warranty is one year. Within the warranty period, we can offer technique support and

part parts change, necessarily, our engineers may go to your place for better service.

8.How about the packing for machine, is it safely protected during transportation?

Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many

testing machines abroad by sea or by air without damage.

9.What is the order process?

Inquiry - quotation - communication - order confirming - deposit payment - production - testing and

debugging - balance payment - packing - delivery - customer receiving - after service.

10.How to install and use the product

The product is shipped with an operating instructions and video of English version.
