[Scope of application]:

This instrument is suitable for taking photos and measuring the size of the sample before and after the experiment, comparing the size before and after the experiment, and automatically calculating the shrinkage rate of the sample.

[Related standards]:

Test Standard：AATCC135, AATCC 150, AATCC 160, AATCC 179, BS EN 3759, BS 4931, ISO 3795,

ISO6330, ISO5077, GB/T 8628, GB/T 8630, GB/T 8631, GB/T 8632, M&S P1C, M&S P4B, NEXT TM12, NEXT TM14, etc.

[Instrument overview]:

1. Use high-definition camera to accurately identify the sample;

2. Software intelligent algorithm, accurately measure the size and calculate the result;

3. Equipped with fill light function to make up for the lack of ambient light;

4. Historical data query, direct export of experimental report.

[Technical parameters]:

1. Camera parameters: 8 million pixels, auto focus;

2. Camera power supply: USB 5V power supply, current 160mA-260mA;

3. Fill light parameters: DC15V, 300mA, color temperature 4000K;

4. Sample size: 500mm×500mm;

5. Overall dimensions: 680mm (length) × 740mm (width) × 880mm (height);

6. Weight: 31.5kg.
